6-Stage Ultrafiltration (UF) Water Purifier with UV Sterilizer

6-Stage UF Filtration with Final UV Treatment

A compact under-sink filtration system designed for ambient drinking and cooking water in homes, apartments and offices. Filtration operates using normal inlet-water pressure; electricity is required for the final 6 W UV sterilizer. Choose All White housings (most popular) or All Transparent housings.

Six-Stage Filtration Process

1. PP Sediment Filter: Captures sediment such as sand, silt and rust to protect downstream filters.
2. UDF Granular Activated Carbon: Helps reduce residual chlorine, unwanted tastes and odours.
3. CTO Carbon Block: Provides additional carbon filtration to help reduce chlorine, tastes and odours.
4. UF Ultrafiltration Membrane: A 0.01-micron membrane provides fine physical filtration while allowing naturally occurring dissolved minerals to remain in the water.
5. T33 Post-Carbon Filter: Helps improve taste and odour before the UV stage.
6. 6 W UV Sterilizer: Installed after T33, this final stage uses ultraviolet light to help inactivate microorganisms in passing water. It includes a 304 stainless-steel chamber, quartz tube and UV lamp. Performance depends on water clarity, flow rate, lamp condition and a clean quartz tube.

Recommended Filter Replacement Schedule

Replacement intervals vary depending on incoming water quality and daily usage.

Note: This product is designed primarily for city water. As an ultrafiltration system, it does not reduce dissolved salts or TDS in the same way as a reverse-osmosis system. Flush new filters ~30 minutes thoroughly before first use.

Warranty: 1-year warranty against manufacturing defects.

UV Installation and Care

Check the supplied power adapter input label before connecting. Keep electrical components dry. Disconnect power and isolate the water supply before servicing. Never look directly at an operating UV lamp or expose skin to its light. Inspect and clean the quartz tube according to the equipment instructions.
